Model: FX-320
Type:Automatic packing machine
Order Hotline:0760-22122022LCD panel microcomputer control;
Bag system with stepping motor technology, automatic tracking, positioning color packing bag;
Automatic print batch number or production date;
According to the order requirement, the product can be cut off;
Rotary material tray, to achieve a high precision count, the number of tablets in the shape of the product is made into the four position, each group according to the need to match the order of the hole. Because of the change of the packing material, the number of tablets can be replaced easily.
The italic feeding turntable materials can be used for packaging goods needing accurate grain number, and in the process of packaging material clamping phenomenon can be reduced.
The set in place, easy to complete from the bag to the packaging production process;
Automatic shutdown function with set packing quantity.
Automatic packaging master for round and ball materials in food and chemical products. Such as sugar coated tablets, tablets, chocolate beans, capsule, steel, glass beads etc.. Applicable to the pharmaceutical, food, chemical, metal, pesticide etc. pouch packaging.
To package material: Polypropylene / polyethylene, polyester / aluminum foil / polyethylene, polyester / aluminum / polyethylene, nylon / polyethylene etc..
Model: FX-320
Packaging form: back seal
Power supply: single phase 220V/50HZ
Power: 2.2KW
Metering methods: custom number plate
Filling range: 2-9 grain / bag (replacement of the number of tablets can be achieved by other number of packaging)
Bag width: 40mm-145mm
Bag length: 60mm-150mm
Packing speed: 20-60 / min
Outline dimension: 710 * 520 * 1550mm
Outer packing size: 800 * 600 * 1600mm
