Model: FX-320 Piston pump type
Type:Automatic packing machine
Order Hotline:0760-22122022The device adopts microcomputer control system, Chinese and English display, intuitive display operation set the technical parameters.
Touch button control, easy human-computer dialogue.
Adopt stepless speed regulation device, the speed regulation process need not stop.
Using microcomputer to control the photocell track system, equipped with high-precision stepper motor, precise patterns on each packing bag of the same position. For the printing of the packaging film, but also in the operating surface directly set the length of the bag. The use of the color of the packaging film, the first bag that can capture color, make the bag pulling simultaneously and stably and accurately.
Function: This machine. If all matching complete, it can be automatically completed quantitative, bag making, filling, filling, sealing alloy (optional reticulate, straight lines and smooth sealing effect, (code), ("-", "V" shape easy tearing mouth), cutting (incision: zigzag incision, even bag easy to tear, sliced, etc.), count to product output to complete a one-time.
The machine can also be matching with punching, automatic feeding machine, belt machine output, let the machine performance can play a greater role in, realize automatic feeding, automatic packaging, automatically send the finished product automatic production process.
Using electric or pneumatic volumetric measurement method for different material characteristics, can be used to select the configuration of electric liquid filling mechanism or piston pump type mechanical filling method.
The machine automatically measuring, bag making, filling, sealing alloy (liquid packaging commonly used strip heat sealing effect, firmness more reliable), (code), (with "I" V "shape easy tearing mouth), cutting (incision: zigzag incision, continuous and easy tearing mouth), count to product output once completed.
Model: FX-320
Packing form: four sides sealing
Power supply: single phase 50HZ 220V
Power: 2.2kw
Metering method: liquid pump
Filling range: 1-30ml, 20-80ml, 50-300ml, 100-600ml (optional)
Bag width: 30-145 (mm)
Bag length: 50-150 (mm)
Packing speed: 20-60 bag / min
Dimensions: 700 x 920 x 1580 (mm)
Outer packing size: 860 * 1030 * 1770 (mm)
